Universal receivers and door openers

Universal multi-frequency receiver with 2 relay outputs and 250V 5A load capability. Works with almost every remote control in the market, fixed and rolling code, AM and FM, transmitting at 433.42, 433.92, 434.15, 434.42, 868.3 868.5, 868.8, 288, 300, 303, 306, 310, 315, 318, 390, 403.55, 418 MHz.

Meanwell HDR-15-12 compatible 12V 15W power supply, DIN rail 1 module (16.5mm width). 100-240Vin 50-60Hz, 10.8-13.8 Vout (adjustable) 1.25A max current.

High performance filtered antenna with stainless steel wall mount bracket, with 3m coax cable RG58 and male-SMA connector.

3m coax cable, RG58, and SMA male connector. Suitable for RFXCOM and other transmitter, receivers, transceivers operating at 433MHz, 434MHz or 435MHz.

2.1dB gain, 2MHz bandwidth, from 433 to 435 MHz

Thanks to the narrow bandwidth, it avoids noise/interference from systems transmitting in adjacent bands.

Very high quality, long life, made in Italy.

Universal multi-frequency receiver with 2 outputs, 60V 50mA load capability. Works with almost every remote control in the market, fixed and rolling code, AM and FM, transmitting at 433.42, 433.92, 434.15, 434.42, 868.3 868.5, 868.8, 288, 300, 303, 306, 310, 315, 318, 390, 403.55, 418 MHz. Also, it can be programmed to work in 2 frequency simultaneously.

Standard antenna with stainless steel wall mount bracket.

2.1dB gain, 15MHz bandwidth, from 860 to 880 MHz

Very high quality, long life, made in Italy.

High performance filtered antenna with stainless steel wall mount bracket.

2.1dB gain, 2MHz bandwidth, from 433 to 435 MHz

Very high quality, long life, made in Italy.

Thanks to the narrow bandwidth, it avoids noise/interference from systems transmitting in adjacent bands.

Standard antenna with stainless steel wall mount bracket.

2.1dB gain, 15MHz bandwidth, from 425 to 440 MHz

Very high quality, long life, made in Italy.

Optional memory for universal receivers like UniRec2.

It can be installed in the receiver to supports a greater number of different remote controls.

Multifrequency micro receiver, 1 channel, operating at 433.42, 433.92, 434.15, 434.42, 868.3, 868.5, 868.8, 315, 403.55, 418 MHz. Can be used to replace a non-working receiver, or to control an existing electronic board by almost any remote control in the market, both fixed and rolling code, AM and FM.
The receiving frequency and modulation can be programmed by the user: also, it's possible to program 2 different frequencies, even with different modulation, to manage remote controls transmitting in 2 different frequencies/modulations: for example the receiver can be used by a set of 433.92MHz OOK and 868.8MHz FSK remote controls.

Multifrequency universal door opener which permit to activate an electric lock or electric strike plate, using almost any remote control in the market, both fixed and rolling code, AM and FM, which transmit in the frequency 433.42, 433.92, 434.15, 434.42, 868.3, 868.5, 868.8, 315 or 418 MHz.

Can be installed in 5 minutes!
